Automatic Dry Mortar Plant

DESCRIPTION

Working principle of automatic dry mix mortar plant :
Dry mortar production line: First the raw material is put into the feed hooper according to mixture ratio, and then, through the action of control system, the equipment can realize automatic feeding, automatic mixing and automatic rationing and packaging. Furthermore, the equipment adopts high-efficiency biaxial agravic mixer as its main mixing system. Requiring little investment and small area but with good efficiency, it shall be an ideal one for small and medium-sized company.

 Advantage of automatic dry mix mortar plant  :
1. In contrast to job-site mortars, dry mortar is also called pre-mixed mortar, which is produced in the factory with dedicated facilities on batching and blending of ingredients in highly-controlled process. It can be used directly just by adding water in job site.
2. It has advantages of consistent quality, controlled inventory ,saving time and labor cost. By adding different chemical additives, it has fine properties of bond, thermal and acoustic insulation, crack-resistance, workability, Water-retention, wear-proof, anti-corrosion, etc.
3. Dry mortar can match different kinds of new construction materials by improving formulation. These good properties not only improve building’s quality and life greatly, but also decrease the usage of mortar in a large degree. 4. The demand for dry mortar has increased rapidly due to its outstanding merit comparing with the mortar mad in job-site.


 Usage of automatic dry mix mortar plant  :
 1. Masonry mortar
 2. Thin and smooth wall mortar
 3. Hand-plastering screeding mortar
 4. Colored coating mortar
 5. Water-proof mortar
 6. Plaster powder
 7. Wall plastering mortar
 8. Ceramic tile adhesive mortar
 9. Self-leveling mortar
 10. Heat-preservation mortar.

.png

Related Equipment

25-30T/H Dry Mix Mortar Plant
Product Category : Automatic Dry Mix Mortar Plant
Capacity: 25-30T/H
Workshop Area: 150-200m²
After-sales Service: Engineer Install

Worker Required: 4-5 Person
Environmentally Friendly: Adopt Pulse Dedust Filter
Measurement: Accurately Batching ,PLC control system
During warranty period, you can get free maintenance, replace the defective parts or components,but except the normal wearing

PARAMETER

Technical Parameter of automatic dry mix mortar plant  :

Mode

Capacity

Area

Height

Note

Semi Automatic Serial

5-15t/h

40-80m2

8-12m

Automatic batching of coarse material,manual
     batching of additive ,automatic packing

Full Automatic

5-50t/h

40-100m2

10-25m

Automatic batching of coarse material,manual
     batching of additive,automatic packing

Full Automatic Tower

55~100t/h

60~500m2

10-30m

Automatic batching of coarse material,manual
     batching of additive,automatic packing
